Here at Fullscript, we use GraphQL to serve data to the front end of our application. It’s a great way to build a flexible API that can be customized and consumed by a variety of clients. However it comes with some complexity surrounding how to load data efficiently without incurring N+1 queries. In this post, we share how we use GraphQL loaders (RecordLoader, ForeignKeyLoader, HasManyLoader) combined with a custom lazy_load helper to avoid N+1 queries in branches, and a custom AutoEagerLoader powered by Goldiloader to resolve complex fields.

The N+1 problem

As many of our readers know, a naive GraphQL implementation can quickly lead to a lot of N+1 queries, especially when dealing with nested data. Take, for example, a user loading their order history: they expect to see each completed order and for each order, the associated line items, product information, image URLs, etc. Without proper handling, this kind of query results in a separate database call for every line item, product, and image. We solve this problem using the graphql-batch gem and loaders.

GraphQL Loaders

We use a combination of GraphQL loaders to handle different ActiveRecord relations. Namely, we use a RecordLoader for belongs_to relations, a ForeignKeyLoader for has_many relations, and a HasManyLoader for has_many :through relations. Similar solutions are well documented elsewhere (See this pganalyze blog post, and this hashrocket blog post), so we won't go into the details here, but we'll point out some differences in our solution. Here's a simplified example from our implementation:

1class ForeignKeyLoader < BaseLoader
2  class << self
3    def loader_key_for(model, column:, scope: nil)
4      [self, model, column, scope.try(:to_sql)]
5    end
6  end
7  ...
8end
9
10class ProductType < GraphQL::Schema::Object
11  field :image, ImageType do
12    argument :size, String, required: true
13  end
14
15  def image(size:)
16    scope = Image.where(size: size)
17    ForeignKeyLoader.for(Image, column: :product_id, scope: scope).load(object.id)
18  end
19end
Copy

The addition of the scope argument allows us to call the loader multiple times in a single requeset with different scopes without the results interfering with each other.

Helper methods

While using dedicated loaders, such as RecordLoader and ForeignKeyLoader, solves the N+1 problem, choosing which one to use can be tedious for experienced developers and confusing for new developers. More importantly, it's completely deterministic. As we mentioned above, belongs_to relations are always loaded with a RecordLoader, and has_many relations are always loaded with a ForeignKeyLoader. To avoid some boilerplate code in our application, we've created a helper method that always picks the right loader for a given relation. Here's an abbreviated version of our helper. The full implementation is in the appendix.

1# abbreviated version
2module Graphql
3  module LoaderHelper
4    def lazy_load(object, association, scope: nil)
5      model = object.class
6      reflection = model.reflect_on_association(association)
7      case reflection
8      when ActiveRecord::Reflection::BelongsToReflection
9        Loaders::RecordLoader.for(reflection.klass, column: reflection.foreign_key, scope: scope).load(object.public_send(reflection.foreign_key))
10      when ActiveRecord::Reflection::HasManyReflection
11        Loaders::ForeignKeyLoader.for(reflection.klass, column: reflection.foreign_key, scope: scope).load(object.public_send(reflection.active_record_primary_key))
12      when ... # more cases
13      end
14    end
15  end
16end
Copy

It’s nothing but a case statement that picks the correct loader for a given record and association using reflection. This simplifies a lot of our types to something like this:

1class ProductType < GraphQL::Schema::Object
2  field :image, ImageType do
3    argument :size, String, required: true
4  end
5  def image(size:)
6    scope = Image.where(size: size)
7    lazy_load(object, :image, scope: scope)
8  end
9end
Copy

Some of our GraphQL fields don’t map directly to an ActiveRecord relation, and require calling the loaders directly, but the lazy_load helper handles about 80% of our cases.

Complex fields

While most of our GraphQL fields map cleanly to a single ActiveRecord record and are handled by loaders like lazy_load, some fields are significantly more complex. These fields often rely on service objects, involve deeply nested associations, or require computed values. Take the example of calculating the total savings on an order:

1class OrderType < GraphQL::Schema::Object
2  field :total_savings, Float
3  def total_savings
4    SavingsCalculator.call(order: object)
5  end
6end
7
8class SavingsCalculator
9  def call(order:)
10    order.line_items.sum do |line_item|
11      line_item.applied_discounts.sum do |discount|
12        discount.amount
13      end
14    end
15  end
16end
Copy

At first glance, this looks straightforward. But under the hood, it accesses multiple nested associations: line_items and their applied_discounts. Without careful handling, this leads to a cascade of N+1 queries.

Why this is tricky

To prevent N+1s in this scenario, we’ve explored a few common approaches:

1. Inject GraphQL loaders into the service object. We would like to avoid this because it makes the service difficult to use elsewhere.
2. Reload the orders using the RecordLoader and the includes method with the correct relations. This can be a bit more efficient, but it requires us to reload the orders and dig into the service logic to know exactly what to preload.
3. Use an aggregating batch loader and Rails’ AssociationPreloader to load the required fields. This avoid querying the same data twice, but still requires us to know which fields are needed upfront, making it a maintenance burden.

All of these approaches work but they have important tradeoffs, and recently we’ve been exploring a new approach.

A more flexible solution: AutoEagerLoader

To resolve complex fields in a performant way, we’ve added the Goldiloader gem to our project and created a custom loader called the AutoEagerLoader that uses it. Goldiloader is a gem that automatically eager-loads a relation for all of the ActiveRecord objects that were loaded together whenever the relation is accessed on the first record. We haven't enabled the library globally because it's too risky for an application of our size, but we've been able to apply it in parts of our GraphQL API to greatly simplify our code. Specifically, our AutoEagerLoader wraps ActiveRecord objects and enables Goldiloader locally to prevent N+1 queries in service calls. Here's a simplified version of the loader:

1class AutoEagerLoader
2  ...
3  def wrap(object, &block)
4    aggregate(object) do |objects|
5      auto_include_context = Goldiloader::AutoIncludeContext.new
6      auto_include_context.register_models(objects.flatten.compact)
7      objects.flatten.compact.each do |obj|
8        obj.auto_include_context = auto_include_context
9      end
10    end.then do |obj|
11      Goldiloader.enabled do
12        block.call(obj)
13      end
14    end
15  end
16end
Copy

The loader works in four steps:

1. It aggregates the different records that are used in a GraphQL field by hooking into the load method of the BatchLoader.
2. It connects the ActiveRecord objects together through a Goldiloader context object. This lets Goldiloader preload associations across the correct records as soon as one is accessed and avoids N+1 queries.
3. It enables Goldiloader locally since it isn’t enabled globally in our application.
4. It forwards the “wrapped” ActiveRecord object to the original block. This is where developers can call a service object or any code that needs to load nested records without having to worry about N+1s.

We then wrap this loader in a simple helper:

1module Graphql
2  module LoaderHelper
3    def auto_eager_load(object)
4      key = caller.grep(/_type.rb/).first || caller[0] # automated unique identifier
5      Loaders::AutoEagerLoader.for(key).wrap(object) do |wrapped_object|
6        yield wrapped_object
7      end
8    end
9  end
10end
11
12class OrderType < GraphQL::Schema::Object
13  field :total_savings, Float
14  def total_savings
15    auto_eager_load(object) do |order|
16      SavingsCalculator.call(order: order)
17    end
18  end
19end
Copy

Limitations

Like ActiveRecord’s includes method, Goldiloader can't eager-load associations with custom conditions (e.g., where, order, limit). In those cases, we still resort to custom loading techniques. But for most complex fields, AutoEagerLoader provides the simplicity of "just call your service" without paying the N+1 penalty.

Recap

In short, with the combination of GraphQL loaders and helpers that we’ve built, we can handle the vast majority of the N+1 queries in our GraphQL API using lazy_load for loading nested records in our GraphQL schema and auto_eager_load for evaluating complex fields. Aggregated statistics is still an open problem, but we're confident that we'll find a neat solution for this, too.

Appendix

Here’s the full implementation of our LoaderHelper module and the AutoEagerLoader class.

1module Graphql
2  module LoaderHelper
3    def lazy_load(object, association, scope: nil)
4      model = object.class
5      reflection = model.reflect_on_association(association)
6      case reflection
7      when ActiveRecord::Reflection::BelongsToReflection
8        klass, options =
9          if reflection.polymorphic?
10            [object.public_send(reflection.foreign_type).constantize, scope: scope]
11          else
12            [reflection.klass, column: reflection.join_primary_key, scope: scope]
13          end
14        Loaders::RecordLoader.for(klass, **options)
15          .load(object.public_send(reflection.foreign_key))
16      when ActiveRecord::Reflection::HasManyReflection
17        scope ||= reflection.klass.all
18        if reflection.type
19          scope = scope.where(reflection.type => model.polymorphic_name)
20        end
21        Loaders::ForeignKeyLoader.for(reflection.klass, column: reflection.foreign_key, scope: scope)
22          .load(object.public_send(reflection.active_record_primary_key))
23      when ActiveRecord::Reflection::HasAndBelongsToManyReflection, ActiveRecord::Reflection::ThroughReflection
24        Loaders::ManyToManyLoader.for(model, association_name: association, scope: scope)
25          .load(object.id)
26      when ActiveRecord::Reflection::HasOneReflection
27        scope ||= reflection.klass.all
28        if reflection.type
29          scope = scope.where(reflection.type => model.polymorphic_name)
30        end
31        if reflection.scope
32          scope = scope.instance_eval(&reflection.scope)
33        end
34        Loaders::ForeignKeyLoader.for(reflection.klass, column: reflection.foreign_key, scope: scope)
35          .load(object.public_send(reflection.active_record_primary_key)).then do |records|
36          records.first
37        end
38      else
39        raise "Relation of type #{reflection.class} is not currently supported."
40      end
41    end
42
43    def auto_eager_load(object)
44      key = caller.grep(/_type.rb/).first || caller[0]
45      Loaders::AutoEagerLoader.for(key).wrap(object) do |wrapped_object|
46        if block_given?
47          yield wrapped_object
48        else
49          wrapped_object
50        end
51      end
52    end
53  end
54end
55
56# This loader should only be used through the `auto_eager_load` helper
57module Loaders
58  class AutoEagerLoader < GraphQL::Batch::Loader
59    def initialize(record)
60      @record = record
61    end
62
63    def aggregate(key, &block)
64      @perform_callback = block
65      load(key)
66    end
67
68    def wrap(object, &block)
69      aggregate(object) do |objects|
70        auto_include_context = Goldiloader::AutoIncludeContext.new
71        auto_include_context.register_models(objects.flatten.compact)
72        objects.flatten.compact.each do |obj|
73          obj.auto_include_context = auto_include_context
74        end
75      end.then do |obj|
76        Goldiloader.enabled do
77          block.call(obj)
78        end
79      end
80    end
81
82    def perform(objects)
83      @perform_callback.call(objects)
84      objects.each do |object|
85        fulfill(object, object)
86      end
87    end
88  end
89end
Copy
